Chipset

Intel H81  TDP 4.1 W

RAM

Support DDR3 1333/1600 MHz, 2 * DIMM Slot, Up to 16GB

Display

2 * VGA

Expansion

1 * Mini PCI-E

1 * PCI-E X16 slot

1 * SIM Card Slot

Storage

1 * Serial ATA 2.0 Port + 2 * Serial ATA 3.0 Ports

Audio

Realtek ALC662 5.1 Channel HDA Codec , Support MIC/Line-out Ports

Network

2 * Realtek PCI-E NIC RTL8111F for 1000Mbps

I /O

11 * RS232 + 1 * RS232/RS485

6 * Header(USB2.0)  + 2 * Rear I/O(USB2.0) + 2 * Rear I/O(USB3.0/USB2.0)

8 * GPIO

1 * PS/2

1 * Front Audio

1 * Parallel Port

BIOS

AMI UEFI BIOS

Power Supply

DC_12V,12V 5A power adapter

Temp

Storage: -20~75℃

Operating: 0~60℃

Humidity

0~90%Relative humidity, non-condensing

Dimension

280mm*220mm*70mm
